牽引車型號 Model code |
|
QCD20-KM |
QCD25-KM |
||
|
性能 Peformance |
最大牽引力 Max.drawbar pull |
kg(lb) |
2000(4400) |
2500(5500)) |
|
|
最大牽引重量（干燥混凝土地面）Max.towed weight at dry even concrete surface |
牽引單車 With one trailer |
kg |
26000 |
33000 |
|
|
(lb) |
(57200) |
(72600) |
|||
|
牽引列車 With a train of trailers |
kg |
39000 |
49000 |
||
|
(lb) |
(85800) |
(107800) |
|||
|
行駛速度 Travel soeed |
前進 Forward |
km/h(MPH) |
26(16.2) |
||
|
后退 Backward |
km/h(MPH) |
26(16.2) |
|||
|
額定牽引力 Rated drawbar pull |
kg(lb) |
800(1765) |
|||
|
最大爬坡度 Max.gradeability |
空載 No load |
% |
45 |
||
|
尺寸 Dimensions |
總長（包括牽引栓） Overall length(with coupler) |
mm(in) |
3070(120.9) |
||
|
總寬 Overall width |
mm(in) |
1440(56.7) |
|||
|
總高 Overall height |
mm(in) |
1420(55.9) |
|||
|
軸距 Wheelbase |
mm(in) |
1600(63.0) |
|||
|
前懸出 Front overhang |
mm(in) |
640(25.2) |
|||
|
后懸出（包括牽引栓） Rear overhang(with coupler) |
mm(in) |
830(32.7) |
|||
|
前輪 Front tread |
mm(in) |
1230(48.4) |
|||
|
后輪 Rear tread |
mm(in) |
1190(46.9) |
|||
|
最小轉彎半徑 Min.turning radius |
外 Outer |
mm(in) |
3265(128.5) |
||
|
地板高度 Floor height |
mm(in) |
425(16.7) |
|||
|
座椅高度 Seat height |
mm(in) |
980(38.6) |
|||
|
牽引栓中心高度 Center height coupler |
mm(in) |
350(13.8) |
450(17.7) |
||
|
牽引裝置長度 Coupler lenght |
mm(in) |
280(11.0) |
|||
|
最小離地間隙 Min.ground clearance |
mm(in) |
130(5.1) |
|||
|
輪胎 Tire |
輪胎尺寸 Tire size |
前輪 Front |
|
6.50-10-10PR（I） |
|
|
后輪 Rear |
|
7.00-15-12PR（I） |
|||
|
重量 Weight |
整機重量（空載） Truck weight(No load) |
kg(lb) |
3550(7830) |
4050(8930) |
|
|
空載軸荷 Weight distrbution |
前軸 Front axle |
kg(lb) |
1100(2430) |
1080(2380) |
|
|
后軸 Rear axle |
kg(lb) |
2450(5400) |
2970(6550) |
||
|
發動機 Engine |
型號 Model |
|
TD27 |
||
|
汽缸總工作容積 Displacement |
cm3(cu.in) |
2663(162.5) |
|||
|
額定功率 Rated output |
日本工業標準 JIS |
PS/rpm |
60/2400 |
||
|
美國 SAE Gross |
HP/rpm |
59/2400 |
|||
|
額定按矩 Rated torque |
日本工業標準 JIS |
kg·m/rpm |
17.5/1600 |
||
|
美國 SAE Gross |
ft·lb/rpm |
130/1600 |
|||
